| Utility Doors |
|
 |
STEEL FACED TIMBER DOORS FOR LOCATION OF REFUSE CHUTE, ROOF, BINSTORE, ELECTRIC CUPBOARD & LIFT MOTOR ROOM |
 |
|
|
|
|
|
|
|
 |
 |
 |
 |
|
| MIL 141 |
MIL 142 |
MIL 143 |
MIL 144 |
|
 |
 |
 |
|
| MIL 145 |
MIL 146 |
MIL 147 |
|
 |
|
|
|
| MIL 148 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Features:
- 44mm thick tri-laminate door blank laminated with 0.9mm steel sheets both sides
- Door edges to be capped with stainless steel channels on all sides
- All steel on door and frame to be powder coated
- Full length gap guard protection to lock
- Custom designs on request
|
|
|
Specification:
Sizes:
- Any size made to order
(however max. size of door leaf will be 1.2m (w) x 2.4m (h))
Ironmongery:
- 12mm stainless steel continuous hinge onto hardwood frame or stainless steel frame
- Stainless steel pull handle 225x22mm or stainless steel long pull handle
- Stainless steel push plate
- Barrel Bolts - on passive door (where double door)
Alternative Frames:
- 80x40x2mm stainless steel hollow section
- 100x50x2mm stainless steel hollow section
- 70x95mm rebated hardwood frame
Hardware:
- Surface mounted door closer
- 2mm Stainless steel full height gap guard
- Metal louvre, Mesh
- Weatherboard (where door is exposed to rain)
Options:
- Upgrade from surface mounted door closer to an LCN2035 concealed door closer
- RX100 low level threshold (if required)
- Fanlights (Solid Panel, Mesh or Louvred)
Locking Options:
- Mul-T-lock
- Gerda Lock
- Mortice Lock
- FB1 or FB2 or FB4 Lock
Finishes:
- Painted - BS or RAL colour
|
|
|
 |
