Communal Entrance Door Jansen Steel Doors
Communal Entrance Doors Communal Entrance Doors Communal Entrance Doors
MIL 121 MIL 122 MIL 123

Communal Entrance Doors Communal Entrance Doors Communal Entrance Doors
MIL 124 MIL 125 MIL 126

Communal Entrance Doors   Communal Entrance Doors
MIL 127 MIL 128

Communal Entrance Doors
MIL 129

Communal Entrance Doors
MIL 130

Categories:

Features:

  • All Doors to be manufactured from 2mm thick mild steel Jansen sections, all joints to be welded and ground to smooth finish. Jansen sections to be shot blasted, hot zinc sprayed and polyester powder coated textured finish, to any BS or RAL No (All Metallic and certain silver paints at extra cost).
  • Complies with Part M regulations for wheelchair access
  • Custom designs on request

Specification:

Sizes:
  • Any size made to order
Ironmongery:
  • 12mm Anti-nip stainless steel continuous hinge
  • Stainless steel pull handle 225x22mm
  • Stainless steel push plate internal face
Alternative Frames:
  • 80x40x2mm stainless steel hollow section
  • 100x50x2mm stainless steel hollow section
Alternative Glazing:
  • Pyroshield georgian wire glass
  • Laminated glass
  • Obscure glass
  • Double glazed sealed unit
Hardware:
  • LCN2035 concealed door closer
  • Stainless steel kick plate internal and external
Options:
  • Magnalock housing to be manufactured from 60x40x2mm (for M32 magnets) or 100x50x2mm (for M82 magnets) stainless steel hollow section fixed with security screws
  • 2-No Magna Locks (Securitron M32 and M32C)

    OR
  • If Secured By Design is required (Tested and Certificated)
    2-No Magna Locks (Securitron M82 and M82C)
  • RX100 low level threshold
  • Fanlights and sidelights
Finishes:
  • Painted - BS or RAL colour
Please Note
All/any electrical equipment to be disconnected and connected by others. Electrical equipment supply and connected by others.
Download Jansen Steel Doors PDF 1
Download Jansen Steel Doors PDF 2
